Magtek Magnetic Stripe Reader

Magtek Magnetic stripe reader with 6-feet USB interface cable. Triple track magnetic stripe track configuration. Hardware compatible with a PC or any computer or terminal having a USB interface. Bi-directional card reading. Reads encoded data that meets ANSI/ISO/AAMVA standards. Reads up to three tracks of card data. Secure red/green/amber LED for status. Compatible with USB specification and HID specification. Can use standard windows HID driver for communications. Programmable USB serial number descriptor, programmable USB interrupt in endpoint polling interval, programmable keyboard table to support alternate languages.

Non-volatile memory for property storage. Detachable USB cable using standard USB Micro-B connector. Supplies 54-byte Magneprint value. Contains a unique, non-changeable serial number that allows tracking each reader. Encrypts all track data and the MagnePrint value. Provides clear text confirmation data including the card holder’s name, expiration date, and a portion of the PAN as part of the masked track data. Interfaces/ports: USB 2.0 USB, PS/2 keyboard wedge. Magnetic stripe track number: track 1, track 2, track 3. Interfaces/ports: USB 2.0 USB and PS/2 keyboard wedge. Environmental conditions- Operating temperature: -22 to 158 degrees F and storage temperature -40 to 158 degrees F. Humidity: 10 to 90 percent non-condensing operating. Certifications and standards: ISO 7810, ISO 7811, AAMVA.

Product features
